商品の詳細:
|
| 部品番号: | AO6802L_001 | 製造業者: | アルファ&Omega Semiconductor Inc。 |
|---|---|---|---|
| 記述: | MOSFET 2N-CH 30V 3.5A 6-TSOP | 部門: | トランジスター- FETs、MOSFETs -配列 |
| 家族: | トランジスター- FETs、MOSFETs -配列 |
| Part Status | Obsolete |
|---|---|
| FET Type | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 3.5A |
| Rds On (Max) @ Id, Vgs | 50 mOhm @ 3.5A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 5nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 210pF @ 15V |
| Power - Max | 1.15W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-74, SOT-457 |
| Supplier Device Package | 6-TSOP |
| Shipment | UPS/EMS/DHL/FedEx Express. |
| Condtion | New original factory. |
コンタクトパーソン: Darek
電話番号: +8615017926135
